Operation image

Vacuum Pad with Lock Function

　　　　　
Free Lock Pad

It will introduce operation examples of the Free Lock Pad.
Click on each image to see operation image.

Basic action
Basic action of Free Lock Pad 1
A stable material handling of workpiece shape with lockable ball joint and lockable buffer.
Mixed production transfer
Handling for mixed production of Free Lock Pad 1
Flexible handling with one tool for workpiece of different shapes.
Changing the suction position
Changing the suction position of Free Lock Pad 1
Handling for mixed production that changed the suction position by using slide mechanism.
　　　　　
Suction in horizontal position
Suction with horizontal position of Free Lock Pad 1
Recommended type in horizontal position.
Suction in upward position
Suction with upward position of Free Lock Pad 1
Suction conveyance in upward position and clampless stand.
Suction conveyance with the individual lock
Suction conveyance with the individual lock of Free Lock Pad 1
Suction conveyance with the individual lock is adjusted the kind of the workpiece.
